Compelling design, elevated.
Techstyle® Graphic panels offer a selection of organic, abstract and geometric designs created specifically for the ceiling plane.
Overview
This range of patterns can be re-scaled and re-colored to fit many room schemes, adding additional visual interest to the environment.
Product Details
Suspension Systems
Swing Down
Lay-In
Echelon™
Key Features
- Proprietary formaldehyde-free fiberglass composite construction
- Monolithic appearance – large format panels, semi-concealed suspension, nominal ¼" reveals
- Convenient swing-down access to the plenum
- Trims are engineered for fast installation of Techstyle®
- Lighting and diffuser integration
- Enhanced soiling resistance and clean-ability
- Formaldehyde free
- Class A Fire Rating, per ASTM E84
- GREENGUARD Gold Certified
Panel Sizes - Swing-Down, Echelon™ System
| 48" x 6" | 48" x 24" | 48" x 42" | 48" x 48" |
| 48" x 54" | 48" x 60" | 48" x 66" | 48" x 72" |
| 24" x 6" | 24" x 24" | 24" x 42" | 24" x 48" |
| 24" x 54" | 24" x 60" | 24" x 66" | 24" x 72" |
| 24" x 78" | 24" x 84" | 24" x 90" | 24" x 96" |
| 30" x 6" | 30" x 30" | 30" x 60" | 30" x 72" |
Panel Sizes - Lay-In
| 48" x 6" | 48" x 24" | 48" x 42" | 48" x 48" |
| 48" x 54" | 48" x 60" | 48" x 66" | 48" x 72" |
| 48" x 96" |
| 24" x 6" | 24" x 24" | 24" x 42" | 24" x 48" |
| 24" x 54" | 24" x 60" | 24" x 66" | 24" x 72" |
| 24" x 78" | 24" x 84" | 24" x 90" | 24" x 96" |
| 24" x 120" |
| 30" x 6" | 30" x 30" | 30" x 60" | 30" x 72" |
| 30" x 96" |
Physical Data
- Surface Finish: Non-woven
- Light Reflectance: 81% (LR1) ASTM E1477
- Surface Burning: Class A (ASTM E84)
- Flame Spread Index < 25
- Smoke Index < 50
- Acoustical Ratings - NRC: 0.85 (ASTM C 423)
- Acoustical Ratings - CAC: 17 w/no backer, (ASTM E1414)
- Moisture Resistance: Resistant to 95% humidity in 104 temperature
- Fungal Resistance: Resistant (ASTM C1338)
- Weight: 0.30 lbs. per sq. ft.
- Warranty: 10 year limited
- ICC: Approval (ESR-2123)
Techstyle® Graphic - Graphics
Client specific colors available. Minimum order quantity - 1,000 sq. ft.
NOTE: Colors are for illustration purposes only.
Print all swatches.
Print Color PageRequest a sample by emailing us.
techstyle.samples@hunterdouglas.comREVIT, CAD & PDF
Click on the + sign to view and download details and drawings for the product(s) listed below.
Installation
Acoustics
Techstyle Graphic panels' honeycomb design absorbs both high and low frequencies at an impressive level, providing superior acoustical performance, no matter the frequency.
NRC 0.85 (ASTM C 423) SAA 0.89 (ASTM C 423)
Sustainability
Overview
Hunter Douglas utilizes metal, wood and fiberglass materials to design, engineer and manufacture ceiling systems that optimize interior environmental quality, material resources and energy usage. Hunter Douglas incorporates sustainable materials and employs sustainable practices in our manufacturing processes. When applied as part of an overall building plan for new and renovation construction, solutions from Hunter Douglas may contribute to LEED BD+C and ID+C certification for schools, retail, hospitality, healthcare and commercial interiors.
SmartBIM ecoScorecard
Our ecoScorecard LEED calculator helps customers search and evaluate the impact of Hunter Douglas' ceilings products against leading environmental rating systems. Using the most up-to-date data in the marketplace, ecoScorecard provides clear, concise product information as well as supporting documentation.
Indoor Environmental Quality
Hunter Douglas is committed to meeting the growing demand for healthier, more sustainable products. Meeting the rigorous and comprehensive standards for low emissions of VOC's, our Greenguard Gold Certified ceilings contribute to the overall indoor air quality and general health of a building space.
Certifications
MEP Coordinations
| Name | Download |
|---|---|
| 4" Grid Gammalux GB46RC2TS | |
| 6" Grid Gammalux GB64RC2TE | |
| 6" Grid CTRS Gammalux GB66RCTE | |
| 6" Grid CTRS Mark Lighting SL6-TS-6XM-T5 | |
| 6" Grid CTRS Mark Lighting SL6-TS-6X-1 | |
| 6" Grid CTRS Mark Lighting BFL-TS-6X-T5 | |
| 6" Grid CTRS Neoray PDR-23DR | |
| 6" Grid CTRS Picasso Lighting - Proner | |
| 6" Grid CTRS Zumtobel 367 |
Document Library
| Name | Download |
|---|---|
| Ceilings & Walls - Product Guide 2017-2018 | |
| Techstyle Graphic - Product Guide Pages | |
| Techstyle Brochure - 2017 | |
| Echelon Brochure | |
| Echelon - System Overview | |
| Technical Specifications - Echelon | DOCX |
| Technical Specifications - Techstyle Graphic - Lay-In | DOC |
| Technical Specifications - Techstyle Graphic - Swing-Down | DOC |
| HVAC Considerations | |
| SDS | |
| GREENGUARD Gold Certificate | Link |
| ICC Evaluation Report - ESR 2123 | |
| Warranty | |
| Cleaning Instructions |
